Building type
Product Name
Operator (building type)
Model
KM-641A
Introduction



Features

 Acceptable leak alarm signal, and sends a signal to the shutoff valve.
 To accept earthquake alarm control panel signals, and send the letter & nbsp; number to shutoff valve.

 Receiving an emergency signal (manual pressure deduction), and issued letters & nbsp; number to shutoff valve.

 Accepts a signal and an alarm sounds, and other functions.




Applicable space:







Model
KM-641A
Alarm device
KN-60KA，KP-15
Cover off valve
V-00，VM-00
Power supply voltage
AC100V，50/60HZ

Alarm device

Action means light

12V input when the red light (gas leak shut-off valve is closed)

Valve means light
Valve opening - the green light is on, the valve closed - Red lights
Alarm bell
When the valve is closed Ming moving
Shutoff valve wire length
Line impedance 2 ohms (reciprocal)
Sell electricity consumption
Approximately 1W
Weight
About 320g
